Home 500m3/H Heating Recovery Ventilator With Hepa Filter

500m3/H Low Noise PM2.5 Purifier HRV Heating Recovery Ventilator

PM2.5 Purifier Heating Recovery Ventilator Competitive Price High Efficiency

What is Heating Recovery Unit(HRV)?

Heat recovery ventilation (HRV), also known as mechanical ventilation heat recovery (MVHR), is an energy recovery ventilation system

which works between two sources at different temperatures.

Heat recovery is a method which is increasingly used to reduce the heating and cooling demands (and thus energy costs) of buildings.

By recovering the residual heat in the exhaust gas, the fresh air introduced into the air conditioning system is pre-heated (pre-cooled),

and the fresh air enthalpyis increased (reduced) before the fresh air enters the room or the air cooler of the air conditioning unit performs heat

and moisture treatment.

A typical heat recovery system in buildings consists of a core unit, channels for fresh air and exhaust air, and blower fans.

Building exhaust air is used as either a heat source or heat sink depending on the climate conditions, time of year and requirements of the building.

Heat recovery systems typically recover about 60–95% of the heat in exhaust air and have significantly improved the energy efficiency of buildings .

NANYOO HRV Category

* Normal High Efficiency HRV

* Ultra-thin PM2.5 HRV

* Big Air Volume Commercial HRV

Model	Air Volume (m3/h)		Static Pressure (Pa)		Rated Voltage	Input Power (W)		Summer				Winter				Noise [dB(A)]		Dimension(mm)	Re. weight (kg)
	Air Volume (m3/h)		Static Pressure (Pa)			Input Power (W)		Temperature Efficiency (%)		Enthalpy Efficiency (%)		Temperature Efficiency (%)		Enthalpy Efficiency (%)		Noise [dB(A)]
	High	Low	High	Low		High	Low	High	Low	High	Low	High	Low	High	Low	High	Low
K-02DT	200	100	75	80	220V/50Hz-60Hz	65	70	76	75	59	58	76	75	69	69	30	28	665×580×268	26
K-03DT	300	250	85	75	220V/50Hz-60Hz	107	78	76	77	56	60	76	77	67	70	30	25	745×600×268	32
K-04DT	400	350	90	80	220V/50Hz-60Hz	142	121	76	77	54	58	76	77	66	68	32	26	745×800×268	38
K-06DT	600	500	100	90	220V/50Hz-60Hz	190	162	70	72	50	53	70	72	61	64	33	31	820900268	48
K-10DT	1000	900	100	80	220V/50Hz-60Hz	410	360	74	77	54	58	74	77	66	70	36	32	1110×1135×388	92
K-16DT	1600	1400	150	130	220V/50Hz	815	750	75	77	57	59	75	77	65	68	42	38	13501220437	95
K-20DT	2000	1800	200	170	220V/50Hz	980	945	76	78	59	61	76	78	66	68	44	40	14501220500	110
K-22DT	2200	1600	100	210		1580	1260	74	77	56	59	74	77	62	67	56	50	1500X1330X500	133
K-16D	1600		150		380V/50Hz	650		75		57		75		65		43		13501220437	98
K-20D	2000		150		380V/50Hz	1013		76		59		76		68		45		14501220500	125
K-25D	2500		110		380V/50Hz	1875		72		54		72		65		50		1550×1330×548	146
K-30D	3000		60		380V/50Hz	1525		75		58		75		68		55		15501330548	165
K-35D	3500		100		380V/50Hz	2245		76		58		76		68		55		16301600548	210

Dimensions and Specifications

Feature
- Super motor, low noise and energy saving.
- 22cm thickness only, widely used in various site.
- High efficiency filter to purify 99.3% PM2.5.
- Reach 73% heating exchange rate.
- Crystal controller, luxury outlooks

Home 500m3/H Heating Recovery Ventilator With Hepa Filter

- Air Volume 2500m³ - 6000m³

We spend 70% of lifetime indoor , be kind to life and breathe fresh air
